Push button Switches

What is a Push Button Switch?
A pushbutton switch (push switches) are devices that are pushed to make or break an electrical circuit. Or to put simply, an object you push to make a device do or stop something. These come in all shapes and sizes, with a multitude of options.

PCB Push button switches?
A PCB switch is a switch that is directly mounted onto a PCB (Printed Circuit Board). Surface mount PCB switches (SMD/SMT) are designed to sit flat, directly on top of a PCB. Through-hole or ‘thru-hole’ PCB switches are inserted into a drilled hole on the printed circuit boards and soldered to pads on the opposite side.

Momentary or Latching function
A momentary switch only works when there is force pressing the button, once this force is removed the switch is no longer engaged. A latching switch maintains the state once pressed, until the push button is pressed again to release the switch.

LED Illumination Options?
RJS supplies both non-illuminated and illuminated push switches. Choosing what type will depend on the function and design of your product. There is a wide range of LED illumination options including single, bi-colour, dual colour or RGB LED illumination. How the illumination is displayed also varies. Variations include;

•Ring illumination
•Dot illumination
•Custom text/symbol illumination
•Full illumination

Push to Make or Push to Break Switch?
A Push to make or ‘Normally Open’ (NO) switch is when an electrical flow is activated in a circuit when the button is pressed. And when the button is released the circuit is then broken and the electrical flow is stopped. This is the most common switch type.
Whereas a Push to Break switch or ‘Normally Closed’ (NC) works in the opposite way, once pressed it stops an existing electrical flow through the circuit.

push button switch circuit, rjs electronics

Poles and Throws
SPST (Single-pole, single-throw) switch has only got one output and one input.

SPDT (Single-pole, double-throw) switches have three terminals, one common pin and two pins which contend for connection to the common. Most suited to devices selecting between two power sources.

DPDT (Double-pole, double-throw) switches are essentially two SPDT switches that control two separate circuits and are switched together by one single actuator.

We operate Monday – Thursday 8 am – 5 pm and Fridays 8 am – 4.30 pm, call us on +44 (0)1234 213600 to speak to our Sales Engineers or e-mail us on [email protected] alternatively, leave us a message using our online contact form.

Download our latest brochure and Product Catalogue. Join our mailing list to get the latest news, read our blog posts and see our latest products.

Read more
  • Broadcast push button switch led illumination, with RGB LED , RJS electronics

    PS011A-N11TBB 15mm

    Push Button Switch, Momentary Switch
    with 15mm cap
    QuickCode: 1304
  • led illuminated push button broadcast switch, available at rjs electronics ltd

    17.4mm² PS011A-N11TBC

    Push Button Switch, Momentary Switch
    with 17.4mm²mm cap
    QuickCode: 1303
  • push button switch with led illumination, broadcast switch - rjs electronics ltd

    PS011A-N11TCD

    Push Button Switch, Momentary Switch
    with 10mm cap
    QuickCode: 1302
  • led illuminated push button switch, broadcast switch - rjs electronics ltd

    17.4mm² PS011A-N11TBBC

    Push Button Switch, Momentary Switch
    with 17.4mm²mm cap
    QuickCode: 1301
  • led illuminated broadcast push button switch - full illumination - RJS Electronics Ltd

    15mm² PS011A-N11TBBCM-2RGB

    Push Button Switch, Momentary Switch
    QuickCode: 1300
  • SPG3 (12mm² Concave)

    Push Button Switch, Momentary Switch
    QuickCode: 1148
  • SPG3 (12mm Flat)

    Push Button Switch, Momentary Switch
    with 12mm cap
    QuickCode: 1147
  • PCB LED ILLUMINATED TACTILE PUSH BUTTON SWITCH, RJS ELECTRONICS

    SPH2N

    Push Button Switch, Tact Switch
    QuickCode: 1141
  • LED ILLUMINATED TACT SWITCH, RJS ELECTRONICS

    SPH2T

    Push Button Switch, Momentary Switch, Tact Switch
    QuickCode: 1140
  • LED ILLUMINATED PUSH BUTTON TACT SWITCH, RJS ELECTRONICS

    SPF Square

    Push Button Switch, Tact Switch
    QuickCode: 1139
  • spc rectangular push button switch led illumination - rjs electronics ltd

    SPC Rectangular

    Push Button Switch, Momentary Switch, Latching Switch
    QuickCode: 1137
  • spc square push button switch with led illumination available at rjs electronics

    SPC Square

    Push Button Switch, Momentary Switch, Latching Switch
    QuickCode: 1136
  • RIGHT ANGLE PCB TACT SWITCH WITH LED ILLUMINATION RJS ELECTRONICS

    TP6151TRML

    Push Button Switch, Tact Switch
    QuickCode: 930
  • LED TACT SWITCHES, RJS ELECTRONICS

    PB61711RFL

    Push Button Switch, Tact Switch
    QuickCode: 929
  • PB6131(XX)RFIL

    Push Button Switch
    QuickCode: 925
  • SP86 push button switch, led illumination, pcb mount, piano rocker switch, rjs electronics ltd.

    SP86NA

    Push Button Switch, Momentary Switch
    2.5mm ± 0.5mm travel
    QuickCode: 920
  • RGB illuminated push button switch, pcb mount, spc range, rjs electronics ltd

    SPCGSB

    Push Button Switch, Momentary Switch, Latching Switch
    2.3mm ± 0.5mm travel
    QuickCode: 919
  • spcg push button switch with led illumination - rjs electronics ltd

    SPCG

    Push Button Switch
    QuickCode: 918
  • Broadcast push button switch with LED illumination, pcb mount, SPG series, RJS Electronics Ltd

    15mm² SPG5

    Push Button Switch, Momentary Switch
    4.5mm ± 0.5mm travel
    QuickCode: 917
  • broadcast switch, push button switch with LED illumination, pcb mount, round cap, rjs electronics ltd

    SPG1 / SPG2 Round 22mm

    Push Button Switch
    QuickCode: 916
🔝
