SS Slide Switch: SS4-CM

Slide Switch



  • Audio & Broadcast
  • Boatbuilding & Marine
  • Home Automation
  • Medical Equipment
  • Industrial Controls



Electrical Operations


Insulation Resistance:

100MΩ min @500 VDC

Contact resistance:

100mΩ max

Dielectric Strength

500 VAC/ 1minute.

Product Series

Mechanical Operations

Contact rating DC 12V 100mA
Function 1P2T
Contact resistance 100 mΩ max.
Insulation resistance 50 MΩ min
Operation force 150+50gf
Travel to closure 1.3mm+0.2mm
Practical temperature range -10°C to +50°C.
