This Super Miniature Illuminated Push Button Switch features a rectangular plastic actuator with LED illumination. It is available with full-face, split-face or dual-colour illumination and accessories can also be added.
Key Features:
| Function | |
|---|---|
| Illumination | Dual Colour Illumination, Split Face Illumination, Full Illumination |
| Single LED options | |
| Depth (mm) | |
| Terminal Options | |
| Mechanical Life (Momentary) | 1,000000 |
| Mechanical Life (Latching) | 2,000000 |
| Dielectric Strength | 600V AC RMS between NC and NO terminal |
| Electrical Operations | |
| Product Series |
| Contact |
Silver Contact (Gold Plated) |
W/E Alloy #1 Cross-bar Contact |
| Electrical Rating |
AC125V, 250V 3A (resistive) |
AC125V 0.1A, DC30V 0.1A (resistive) |
| Insulation Resistance |
More than 100MΩ at 500V DC |
|
| Dielectric Strength |
600V AC RMS between NC and NO terminal 1500V AC RMS between terminals and ground 50/60 Hz for 60 sec. at normal ambient temperature and humidity |
|
| Contact Resistance |
Less than 50mΩ (initial) at DC6V 1A |
Less than 50mΩ (initial) at DC6V 0.1A |
| Mechanical Life |
Momentary Action: more than 1,000,000 operations Latching Action: more than 200,000 operations |
|
| Electrical Life |
More than 30,000 operations at max rated load |
|
| Ambient Temperature |
-15°C to +50°C |
|
| Ambient Humidity |
80% RH (max) |
|
| Operating Force (max) |
4.41N |
|
| Total Travel (max) |
2.5mm |
|
