DIP Switches

What are DIP Switches? DIP switch is a small switch in a DIP (dual in-line package) that controls the flow of electricity around a PCB board (printed circuit board).

What are the benefits of DIP Switches?

The main benefits of DIP switches are they are simple to function and are very cost effective. Making them a cheaper alternative to software control panels and jumper blocks. A standard DIP switch can include 1, 2, 4, 7, 8, 10, 16+ switches mounted on 1 single small block.

Types of DIP switches

There are many different types of DIP switches, these include;

Piano Type

Piano type dip switch, rjs electronics ltd

Slide Type

Slide type dip switch, rjs electronics ltd

IC Type

IC type dip switch, rjs electronics ltd

SMD Type

SMD dip switches, rjs electronics ltd

Right Angle Type

Right angle dip switch, rjs electronics ltd

Rotary Dip switches

A dip switch with a circular motion instead of a toggle going back and forth. They can rotate through 360 degrees or alternatively can be preset to stop at certain positions. This type is perfect for PCB boards with limited space.

Poles and Throws?

Our DIP switches are available with a variety of pole and throw configurations, such as:

  • Single pole single throw (SPST)
  • Single pole double throw (SPDT)
  • Double pole double throw (DPDT)

Typical Applications

  • PC hardware, for example modems and hard drives.
  • Door opening mechanisms
  • Multi-device remote controls
