Non-Illuminated PCB tact Switch with momentary function. Suitable for a wide range of applications.
Key Features:
| Product Series | |
|---|---|
| Illumination | |
| Configuration | |
| Orientation | |
| Function | |
| IP Rating |
| Waterproof Degree: | IP67 | Operating force: | 180/250±30gf |
| Operating Direction: | Top Push | Travel: | 0.25mm |
| Operating Life: | Over 100,000 cycles | Initial contact resistance: | 100mΩ max. |
| Stem height: | H=7.3mm | Operating Temperature: | -25℃~+105℃ |
| Rating (max.): | 50mA 12V DC | Rating (min.): | 10µA 1V DC |
| SPQ: | 1,000pcs | OEM or ODM: | Available |
