22mm metal push button switch, Ring LED illuminated, antivandal switch, panel mount, LED SWITCHES, RJS Electronics Ltd
RJS1N1-22L-H-R~65Q - Image 2
RJS1N1-22L-H-R~65Q - Image 3

RJS1N1-22L-H-R~65Q

This 22mm Anti Vandal Switch has a panel cut out of Ø 22mm and does not have LED illumination. Its high head actuator allows for easy operation and it has a momentary function. It is rated IP65 from the front, providing protection against dust and water.

Key Features:

  • Ø 22mm Panel cut out
  • Momentary
  • High head
  • Ring LED illuminated
  • Single/Bi-colour LED options
  • 3V-24V DC LED
  • IP65 rated (from the front)
  • 1NO SPST [Push to make]
Data Sheet
IP Rating

Configuration

Terminal Options

Illumination

Cap / Actuator Shape

,

Function

Panel Cut-Out Diameter
