These PCB mount Slide Switches feature an SPDT or DPDT configuration with vertical or right-angle mounting. Choose from 2 or 3 positions and a range of actuator heights.
Key Features:
| Product Series | |
|---|---|
| Function | |
| Configuration | |
| Orientation | |
| Terminal Options |
| Contact rating | |
| Mechanical life | 30,000 make-and-break cycles |
| Contact resistance | 10mΩ max initial. @2-4VDC
100mA for both silver and gold plated contacts |
| Insulation resistance | 1,000 MΩ min |
| Dielectric strength | 1,000 vms min @sea level |
| Operating temperature | -30°C to 85°C |
