| Product Series | |
|---|---|
| Function | |
| Illumination | |
| IP Rating | |
| Operating Temperature Range | -20°C-70°C |
| Terminal Options |
Panel mount LED Touch Sensor Switch with full LED illumination, choose from an array of colours. Features IP67 rating (from the front).
Key Features:
| Product Series | |
|---|---|
| Function | |
| Illumination | |
| IP Rating | |
| Operating Temperature Range | -20°C-70°C |
| Terminal Options |
TS003 specifications
| Switch specifications | |
| Pole–position | One-channel |
| Circuit feature | Capacitive analog signal |
| Operating temperature range | -20°C~70°C |
| Sealing | IP67 |
| LED specifications | ||||
| ATTENTION
LEDs are electrostatic sensitive devices |
Unit |
Value/LED colour | ||
| Ultra green | Ultra yellow | Ultra red | ||
| Forward current (lf) | mA | 20 | 20 | 20 |
| Reverse voltage (Vr) | V | 5.0 | 5.0 | 5.0 |
| Reverse current (lr) | µA | 10 | 10 | 10 |
| Forward voltage@20mA (Vf) | V | 2.1-2.5 | 2.0-2.5 | 2.0-2.5 |
| Luminous intensity@20mA (lv) | mcd | 60 | 120 | 150 |
