MLC – Square Domed Type

This Ultrabright LED Indicator features a square domed cap and single or dual-colour LED illumination. Its IP65 rating and ultrabright illumination make it ideal for outdoor applications.

Key Features:

  • 30mm x 30mm x 29mm
  • Single/dual colour LED illumination
  • Ultrabright LED type
  • Diamond-cut cover
  • IP65 rated
  • Accessories available
  • Full MLC series
Function

Illumination

Bezel Shape

IP Rating

Single LED options

, ,

Multi-Colour LED Options

Cap / Actuator Shape

Insulation Resistance

100M Ω or greater with DC 500V megger

Dielectric Strength

Between terminals and ground: AC 1500VRMS, 50/60Hz for 60 sec. at normal temp. and humidity.

Product Series

MLC Series specifications

Insulation resistance 100MΩ or greater with a DC 500V megger
Dielectric strength 1500V AC RMS between terminals and ground (50/60Hz for 60sec. at normal ambient temperature and humidity)
Reverse dielectric strength 150V
Ambient temperature -10°C~+50°C
Ambient humidity 80% RH or less

LED Indicator Panel - Domed Sq Type - Drawing - MLC - LED Panel Indicator - RJS Electronics Ltd.
