NJ70+NJ71

• Relay

• Small size, lightweight (8g)
• Withstands high temperature, operating under 105°c ambient temperature.
• Heavy contact load switching current upto 30A.

  • Suitable for automotive and lamp accessories application.



Function

Contact Arrangement

2A (DPSTNO) ,2C (DPDT(B-M))

Contact Rating

Resistive: 2A:30A,20N14VDC
2C:NO:30A,20A/14VDC; NC:25A, 15N14VDC

Max. Switching Power

420W

Max. Switching Voltage

24VDC
Max. Switching Current:30A

Contact Resistance or Voltage drop

<30mV (at 10A)

Electrical Operations

Mechanical Operations

Sizing (mm)

23.6X 12.9X9.9
